AC to DC Converter

Universal AC to 48V DC (3.2 Amps)

AC to DC Converter - Universal AC to 48V DC (3.2 Amps)

Description

Valiant's AC to DC converter may be used to convert 85V AC-264V AC, 47Hz-63Hz AC Mains Input Voltage to 48V DC output voltage. It may be also used to convert 120V DC - 370V DC Input Voltage to 48V DC Output Voltage. Available with 3.2 Amps (150 Watts) in a 19 Inch Rack Mount version.

This AC to DC converter is designed for telecom applications requiring stable DC voltage with low EMI and EMC interference. This is an external converter power supply which is available in a destop version, with one fuse protected output.

Data SheetAC-DC Converter: Universal AC (85V AC-264V AC, 47Hz-63Hz) to 48V DC - 19 Inch Rack Mount Version

Features

  • Converts universal AC Mains Input (85V DC -264V AC, 47Hz - 63Hz) to 48 VDC, 3.2 Amps - 19 Inch Rack Mount Version
    • `
  • Converts 120V DC to 370V DC to 48V DC output current @ 48V DC = 3.2 Amps
  • Small and compact
  • High quality and cost effective
  • Auto ranging voltage
  • UL, recognized, TUV approved, CSA certified
  • Built-in inrush current, over current and over voltage protection circuits
  • Harmonic attenuator, PFC (Complies with IEC61000-3-2)
  • Rugged PCB type construction
  • RoHS Compliant.

Related Links

Application Diagram

Convert 85V AC-264V AC, 47Hz-63Hz AC Mains Input Voltage to 48V DC output voltage

INPUT VOLTAGE [V] AC 85-264, 47Hz - 63 Hz
DC 120-370
MAX OUTPUT WATTAGE [W] 151.2 (Peak 288)
DC OUTPUT 6.3 A @ 24V DC
